12.8V 20Ah Lithium Iron Phosphate Battery

Renogy Core Mini 12V 20Ah Trolling Motor LifePO4 Battery: Featherlight Power for Stealthy Pursuits

Need a compact LifePO4 battery for quiet, reliable trolling-motor power? Meet the Renogy Core Mini 12V 20Ah Lithium Iron Phosphate Battery, built for stealthy runs and easy carry.

It weighs just 5.95 lbs (2.7 kg). The small case measures 7.13 x 3.03 x 6.61 inches, so it stows cleanly on a kayak or small deck.

You cut 50% of the weight versus lead-acid. You also gain up to 30% more runtime for longer sessions on the water.

Capacity is 20Ah (256Wh) of usable energy. It delivers 4,000+ cycles at 80% DOD, which is up to 8x the life of AGM.

Voltage stays steady at 12.8V output under 20A continuous loads. That makes it a strong match for solo powering 30 lb thrust motors.

It also supports extended fish-finder use. The stable output helps keep your electronics running consistently.

Safety is handled by an integrated 20A BMS. It adds 20+ safeguards against overcharge, short circuits, and more.

Charging stops below 32°F. For use outdoors, it discharges from -4°F to 140°F and carries IP65 dust/water resistance.

Need room to grow? This LifePO4 battery is expandable up to 16 units in series/parallel for larger systems.

For monitoring, pair it with Renogy's Shunt 300 (sold separately). There is no Bluetooth built in, but app-based tracking is still possible.

It’s tailored for kayaks, bass boats, e-scooters, ham radios, and portable solar. It’s maintenance-free and eco-safe with Grade A cells.

For shoppers comparing everyday essentials like "batteries and bulbs", this is a premium option for deep-cycle use. If you’re replacing an "800 battery", confirm size, voltage, and load needs first.

Backed by a 5-year warranty, this LifePO4 battery helps you haul less and stay on the bite longer. Light as a lure, tough as your tackle box.
